232RS6
232RS6
Clasificación
- E-Number (Sweden):
- E2416491
- E-Number (Finland):
- 2421212
- E-Number (Norway):
- 1542332
- EAN:
- 7392696931229
- Country of Origin:
- Czech Republic (CZ)
- Cantidad mínima de pedido:
- 10 piece
Dimensiones
- Ancho del product:
- 85 mm
- Alto del producto:
- 118 mm
- Peso del product:
- 0.3 kg
- Mechanical Drawings:
- 9AKK107991A3804
Información de Embalaje
- Embalaje Nivel 1 Ancho:
- 188 mm
- Embalaje Nivel 1 Largo:
- 175 mm
- Embalaje Nivel 1 Alto:
- 428 mm
- Embalaje Nivel 1 Peso:
- 3 kg
- Embalaje Nivel 1 EAN:
- 7392696661225
- Embalaje Nivel 1 Unidades:
- box 10 piece
- Package Level 2 Width:
- 800 mm
- Package Level 2 Depth / Length:
- 1200 mm
- Package Level 2 Height:
- 900 mm
- Package Level 2 Gross Weight:
- 740 kg
- Package Level 2 EAN:
- 7392696079259
- Package Level 2 Units:
- pallet (lift) 240 piece
Ambiente
- RoHS Status:
- Following EU Directive 2011/65/EU
Certificados y Declaraciones (Número de Documento)
- Declaración de conformidad – CE:
- 2CMC700005D0001
- Environmental Information:
- 2CMC000056M0000
- RoHS Information:
- 2CMC700005D0001
- SEMKO Certificate:
- 1613211
- REACH Declaration:
- 2CMC700005D0001
Información Adicional
- Additional Information:
- 2P+E
- Ambient Temperature:
- -25 … 40 °C
- Cable Cross-Section:
- 2.5 … 10 mm²
- Cable Diameter:
- 22 mm
- Cable Entry Position:
- Cable entry, flexible membrane and metric threaded M25 insert for top cable entry.Rear knock-out cable entry.
- Color:
- Blue
- Connection Type:
- Screw
- Grado de protección:
- IP44
- Frequency (f):
- 50 Hz
60 Hz
- Function:
- Wall mounted socket
- Housing Material:
- Plastic (PA)
- Invoice Description:
- Ind. P&S#232RS6
- Mounting Holes:
- 111×72
- Mounting Type:
- Angled
- Number of Poles:
- 3
- Order Multiple:
- 10 piece
- Product Main Type:
- ERS
- Product Name:
- Wall mounted socket
- Protection Type:
- Splashproof
- Rated Current (In):
- 32 A
- Rated Voltage (Ur):
- 200 … 250 V
- Recommended Screw Driver:
- PH2
- Standards:
- IEC 60309-1, -2
- Suitable For:
- Surface Socket Outlets
- Suitable for Product Class:
- IEC Industrial Plugs and Sockets
- Instrucciones y manuales:
- 2CMC700014C0016
- Installation Manual:
- 2CMC700014C0016
- RAL Number:
- RAL 7012 – Gris basalto
Clasificaciones
- eClass:
- 27440510
- UNSPSC:
- 39121406
Technical
- Wire Size:
- 12 … 10 AWG
- Tightening Torque:
- WireClamp1.2 N·m
Surface socket-outlet, 6h, 32A, IP44, 2P+E
