216RAU6W ABB 2CMA166996R1000-TOMA EMPOTRABLE
Ordering
- E-Number (Sweden):
- E2416695
- E-Number (Finland):
- 2421291
- E-Number (Norway):
- 1561902
- EAN:
- 7392696669962
- Country of Origin:
- Czech Republic (CZ)
- Minimum Order Quantity:
- 1 piece
Dimensions
- Product Net Width:
- 95 mm
- Product Net Height:
- 102 mm
- Product Net Weight:
- 0.23 kg
- Mechanical Drawings:
- 9AKK107991A3785
Container Information
- Package Level 1 Width:
- 110 mm
- Package Level 1 Depth / Length:
- 110 mm
- Package Level 1 Height:
- 110 mm
- Package Level 1 Gross Weight:
- 0.23 kg
- Package Level 1 EAN:
- 7392696005692
- Package Level 1 Units:
- box 1 piece
- Package Level 2 Width:
- 800 mm
- Package Level 2 Depth / Length:
- 1200 mm
- Package Level 2 Height:
- 900 mm
- Package Level 2 Gross Weight:
- 116.6 kg
- Package Level 2 EAN:
- 7392696071536
- Package Level 2 Units:
- pallet (lift) 420 piece
Environmental
- RoHS Status:
- Following EU Directive 2011/65/EU
Certificates and Declarations (Document Number)
- Declaration of Conformity – CE:
- 2CMC700005D0022
- Environmental Information:
- 2CMC000056M0000
- RoHS Information:
- 2CMC700005D0022
- SEMKO Certificate:
- 1613211
- REACH Declaration:
- 2CMC700005D0022
Additional Information
- Additional Information:
- 2P+E
- Ambient Temperature:
- -25 … 40 °C
- Cable Cross-Section:
- 1.5 … 4 mm²
- Cable Diameter:
- 6 … 13 mm
- Color:
- Blue
- Connection Type:
- Screw
- Degree of Protection:
- IP67
IP69
- Frequency (f):
- 50 Hz
60 Hz
- Function:
- Receptacle
- Housing Material:
- Thermoplastic (PBT)
- Invoice Description:
- Ind. P&S#216RAU6W
- Mounting Holes:
- 79.5×79.5
- Mounting Type:
- unified flange, angled
- Number of Poles:
- 3
- Order Multiple:
- 1 piece
- Product Main Type:
- TRAU
- Product Name:
- Panel mounted socket
- Protection Type:
- Watertight
- Rated Current (In):
- 16 A
- Rated Frequency (f):
- 50…60 Hz
- Rated Voltage (Ur):
- 200 … 250 V
- Recommended Screw Driver:
- PH2
- Standards:
- IEC 60309-1, -2
- Suitable For:
- Socket Outlets for Panel Mounting
- Suitable for Product Class:
- IEC Industrial Plugs and Sockets
- Instructions and Manuals:
- 2CMC700052M0001
- Installation Manual:
- 2CMC700052M0001
- RAL Number:
- RAL 7001 – Silver Grey
Classifications
- eClass:
- 27440504
- UNSPSC:
- 39120000
Technical
- Wire Size:
- 14 … 12 AWG
- Tightening Torque:
- WireClamp0.8 N·m
Ind. P&S#216RAU6W
