216RAM6 2CMA170004R1000-TOMA EMPOTRABLE 2P+T 16

2CMA170004R1000-TOMA EMPOTRABLE 2P+T 16 AMP. 200-250V AZUL IP44

Ordering

• E-Number (Sweden):

  E2416461

• E-Number (Finland):

  2421404

• E-Number (Norway):

  1564532

• EAN:

  7392696700047

• Country of Origin:

  Czech Republic (CZ)

• Minimum Order Quantity:

  10 piece

Dimensions

• Product Net Width:

  78 mm

• Product Net Height:

  78 mm

• Product Net Weight:

  0.14 kg

• Mechanical Drawings:

  9AKK107991A3698

Container Information

• Package Level 1 Width:

  138 mm

• Package Level 1 Depth / Length:

  158 mm

• Package Level 1 Height:

  345 mm

• Package Level 1 Gross Weight:

  1.4 kg

• Package Level 1 EAN:

  7392696702027

• Package Level 1 Units:

  box 10 piece

• Package Level 2 Width:

  800 mm

• Package Level 2 Depth / Length:

  1200 mm

• Package Level 2 Height:

  900 mm

• Package Level 2 Gross Weight:

  944 kg

• Package Level 2 EAN:

  7392696077712

• Package Level 2 Units:

  pallet (lift) 660 piece

Environmental

• RoHS Status:

  Following EU Directive 2011/65/EU

Certificates and Declarations (Document Number)

• CB Certificate:

  2CHC660153X0201

• Declaration of Conformity – CE:

  2CMC700005D0001

• Environmental Information:

  2CMC000056M0000

• RoHS Information:

  2CMC700005D0001

• SEMKO Certificate:

  1614201

• REACH Declaration:

  2CMC700005D0001

Additional Information

• Additional Information:

  2P+E

• Ambient Temperature:

  -25 … 40 °C

• Cable Cross-Section:

  1.5 … 4 mm²

• Cable Diameter:

  6 … 13 mm

• Color:

  Blue

• Connection Type:

  Screw

• Degree of Protection:

  IP44

• Frequency (f):

  50 Hz
  60 Hz

• Function:

  Panel mounted socket

• Housing Material:

  Plastic (PA)

• Invoice Description:

  Ind. P&S#216RAM6

• Mounting Holes:

  55×55

• Mounting Type:

  Minimized angled flange

• Number of Poles:

  3

• Order Multiple:

  10 piece

• Product Main Type:

  ERAM

• Product Name:

  Panel mounted socket

• Protection Type:

  Splashproof

• Rated Current (I_n):

  16 A

• Rated Frequency (f):

  50…60 Hz

• Rated Voltage (U_r):

  200 … 250 V

• Recommended Screw Driver:

  PH2

• Standards:

  IEC 60309-1, -2

• Suitable For:

  Socket Outlets for Panel Mounting

• Suitable for Product Class:

  IEC Industrial Plugs and Sockets

• Instructions and Manuals:

  2CMC700014C0016

• RAL Number:

  RAL 7001 – Silver Grey

Classifications

• eClass:

  27440504

• UNSPSC:

  39121406

Technical

• Wire Size:

  14 … 12 AWG

• Tightening Torque:

  WireClamp0.8 N·m
