216EP6 – ABB
Ordering
- E-Number (Sweden):
- E2416161
- E-Number (Finland):
- 2420050
- E-Number (Norway):
- 1540708
- EAN:
- 7392696019477
- Country of Origin:
- Czech Republic (CZ)
- Minimum Order Quantity:
- 10 piece
Dimensions
- Product Net Width:
- 57 mm
- Product Net Height:
- 63 mm
- Product Net Weight:
- 0.11 kg
Container Information
- Package Level 1 Width:
- 120 mm
- Package Level 1 Depth / Length:
- 138 mm
- Package Level 1 Height:
- 285 mm
- Package Level 1 Gross Weight:
- 1.1 kg
- Package Level 1 EAN:
- 7392696029797
- Package Level 1 Units:
- box 10 piece
Environmental
- RoHS Status:
- Following EU Directive 2011/65/EU
Certificates and Declarations (Document Number)
- CB Certificate:
- 2CHC660167X0201
- Declaration of Conformity – CE:
- 2CMC700005D0001
- Environmental Information:
- 2CMC000056M0000
- RoHS Information:
- 2CMC700005D0001
- SEMKO Certificate:
- 1617364
- REACH Declaration:
- 2CMC700005D0001
Additional Information
- Additional Information:
- 2P+E
- Ambient Temperature:
- -25 … 40 °C
- Cable Cross-Section:
- 1 … 2.5 mm²
- Cable Diameter:
- 14 mm
- Cable Entry Position:
- Swivel
- Color:
- Blue
- Connection Type:
- Screw
- Degree of Protection:
- IP44
- Frequency (f):
- 50 Hz
60 Hz
- Function:
- Plug
- Housing Material:
- Plastic (PA)
- Invoice Description:
- Ind. P&S#216EP6
- Number of Poles:
- 3
- Order Multiple:
- 10 piece
- Product Main Type:
- EP
- Product Name:
- Industrial Plug
- Protection Type:
- Splashproof
- Rated Current (In):
- 16 A
- Rated Voltage (Ur):
- 200 … 250 V
- Recommended Screw Driver:
- PH2
- Standards:
- IEC 60309-1, -2
- Suitable for Product Class:
- IEC Industrial Plugs and Sockets
- Instructions and Manuals:
- 2CMC700014C0016
- RAL Number:
- RAL 7012 – Basalt Grey
Classifications
- eClass:
- 27440509
- UNSPSC:
- 39120000
Technical
- Wire Size:
- 14 … 12 AWG
- Tightening Torque:
- WireClamp0.8 N·m
